LED strip lights (also known as tape lights) offer versatile and energy-efficient lighting solutions for various applications. However, powering them correctly is crucial for optimal performance and longevity. At BeesLighting.com, we understand the importance of choosing the right power supply or LED driver. This guide will walk you through the essential factors, including driver types, voltage considerations, and safety classifications, ensuring your LED strip lighting project shines.
Understanding LED Power Supplies and Drivers
The terms "power supply" and "LED driver" are often used interchangeably, but they serve the same fundamental purpose: to convert standard AC (alternating current) from your home's electrical system into the stable DC (direct current) that LED strip lights require.
Types of LED Drivers
- Electronic Drivers: These are solid-state devices that efficiently convert AC to DC. They are known for their compact size, efficiency, and reliability. Electronic drivers are a popular choice for LED strip light installations. They are versatile and work with many dimming methods.
- Magnetic Drivers: These utilize transformers to step down the voltage. Magnetic drivers are often favored for their durability and compatibility with certain older dimming systems. They can be bigger and heavier than electronic drivers. However, they are known for their strong performance in certain uses.
12VDC vs. 24VDC: Which Voltage Should You Choose?
- 12VDC: Suitable for shorter runs and simpler installations. It's a common choice for automotive and small residential projects.
- 24VDC: Preferred for longer runs due to reduced voltage drop, allowing for more consistent brightness across the entire strip. This is ideal for larger installations and commercial projects.
Voltage Drop: Ensuring Consistent Brightness
Voltage drop occurs when the voltage decreases along the length of the LED strip, resulting in dimmer light towards the end. This is influenced by wire gauge, strip length, and current.
| Wire Gauge (AWG) | Distance (Feet) | Voltage Drop (Percentage) |
| 18 | 10 | 3.8% |
| 18 | 20 | 7.6% |
| 16 | 10 | 2.4% |
| 16 | 20 | 4.8% |
| 14 | 10 | 1.5% |
| 14 | 20 | 3.0% |
| 12 | 10 | 0.9% |
| 12 | 20 | 1.8% |
* This table provides general guidelines. Actual voltage drop may vary based on specific LED strip characteristics and installation conditions. Always consult with a professional for critical applications.
Class 2 vs. Non-Class 2 Power Supplies:
- Class 2 Power Supplies: These are designed to limit both voltage and current, reducing the risk of electrical shock and fire hazards. They are generally considered safer for residential and DIY installations.
- Non-Class 2 Power Supplies: These provide higher power output but require more stringent installation procedures due to increased safety risks. They are typically used in commercial and industrial applications where higher power demands are necessary.
Selecting the Right Power Supply:
- Determine the Total Wattage: Calculate the wattage required by your LED strip lights by multiplying the wattage per foot by the total length.
- Choose the Correct Voltage: Select 12VDC or 24VDC based on your project requirements and strip length.
- Ensure Adequate Capacity: Select a power supply with at least 20% more wattage than your calculated requirement to account for potential fluctuations and future expansion.
- Consider Dimming Requirements: If dimming is desired, choose a compatible dimmable driver.
- Safety and Certification: Ensure the power supply is UL Listed or ETL certified for safety and compliance.
Choosing the right power supply or LED driver is essential for a successful LED strip lighting project. At Bees Lighting, we offer a comprehensive range of high-quality drivers, including electronic and magnetic options from Magnitude Inc., GM Lighting, American Lighting, and Diode LED. Our knowledgeable team is ready to assist you in selecting the perfect power solution for your needs. Browse our selection and illuminate your space with confidence.
How many feet of LED tape lights can I put on a driver?
The maximum length of LED tape lights you can connect to a driver depends on the wattage of the tape lights and the wattage rating of the driver. To find the total wattage of your LED tape lights, multiply the wattage per foot by the total length. Make sure the driver's wattage rating is higher than this total. It’s best to have a 20% buffer for safety.
What is the difference between Magnetic drivers versus Electronic drivers?
Electronic drivers are solid-state devices known for their efficiency, compact size, and compatibility with various dimming methods. Magnetic drivers use transformers. They are durable and work with some older dimming systems. However, they are usually offer larger wattage.
What is the maximum distance between the driver and the LEDs?
The maximum distance is limited by voltage drop. Longer distances and higher current draw will result in a greater voltage drop, leading to dimmer light output. Using larger gauge wire and 24VDC systems can help mitigate this. Refer to voltage drop tables for specific guidance.
What is the most common reason for driver/LED failure?
The most common reasons include:
Overloading the driver: Exceeding the driver's wattage capacity.
Incorrect wiring: Improper connections can cause shorts or damage.
Voltage drop: Insufficient wire gauge for long runs.
Environmental factors: Exposure to excessive heat, moisture, or dust.
Using a driver that is not compatible with the LED product.
How do I know which Driver is best for my application?
Consider the following factors:
Voltage: Match the driver's output voltage (12VDC or 24VDC) to your LED tape lights.
Wattage: Ensure the driver's wattage capacity is sufficient for your total LED tape light load.
Dimming: If dimming is required, choose a compatible dimmable driver.
Installation Environment: Select a driver with an appropriate IP rating for the installation location (dry, damp, or wet).
Run Length: for longer runs, 24VDC is preferred to reduce voltage drop.
